ESC Windows Pos System Kitchen Thermal Label Printer

Product Categories
SUNLUX IOT Technology (Guangdong) Inc.
Contact Now

ESC Windows Pos System Kitchen Thermal Label Printer

Brand Name : SUNLUX

Model Number : XL-8030

Certification : CE, FCC

Place of Origin : China

MOQ : 20 Pieces

Price : Negotiation

Payment Terms : T/T

Supply Ability : 10000 PCS per month

Delivery Time : within 15 work days if less than 1000 pcs

Packaging Details : 12 pcs in one carton, carton size 53*39*59 cm

Printing Method : Direct thermal

Printing Speed : 260mm/s

Interface Type : USB/LAN/USB/Serial

Print Width : 72mm

Paper Thickness : 0.06-0.08mm

Commands : ESC/POS

Dimension : 184*144*136.8mm

Cutter : Partial

Cutter life : 1million cuts

Print Head life : 100KM

Color : Black

Gross weight : 1.16kg

Contact Now



80MM ESC/POS Command Support Windows Pos System Kitchen printer Thermal receipt printer POS Receipt printer



Product Features

​

  • Product Name: Thermal Receipt Printer
  • 200 mm / sec low noise, high speed printing.
  • Simplified/Traditional can be freely converted by instructions.
  • Support cash box driver.
  • Support kitchen printing, network printing.
  • Support NVLOGO download image printing (picture format is BMP).
  • Built-in power supply design, more convenient and more beautiful to use.
  • Supports print head over-temperature protection to make the print head last longer..
  • Support single prompt and error alarm function.
  • Supports the loss-free function to prevent losing orders.
  • Support a variety of one-dimensional bar code printing.
  • With automatic paper cutting function.
  • With out of paper detection, black mark detection and positioning function (detection is located in the middle of the paper black mark), automatic paper loading function.
  • Product application: widely used in banking, telecommunications, takeaway, shopping malls, hospitals, supermarkets and sports lottery and other fields.





Product Specifications



ESC Windows Pos System Kitchen Thermal Label Printer



 Printing method  Direct thermal
 Printing speed  260mm/s
 Paper width  79.5±0.5mm
 Roll paper  80mm
 Paper thickness  0.06~0.08mm
 Column capacity  576 dots/line 512 dots/line
 Character size  ANK,Font A:1.5×3.0mm(12×24 dots)
 Font B:1.1×2.1mm(9×17 dots)
 Simplified /traditional Chinese: 3.0×3.0mm(24×24 dots)
 Line space  3.75mm(changeable using commands)
 Interface  Serial+USB+Lan/USB+WIFI/USB
 Bar code  UPC-A/UPC-E/JAN13(EAN13)/JAN8(EAN8)/CODABAR/ITF/CODE39/CODE93/CODE128
 Code page  PC347(Standard Europe), Katakana, PC850(Multilingual),P C860(Portuguese), PC863(Canadian-   French), PC865(Nordic),West Europe, Greek, Hebrew, East Europe, Iran, WPC1252,   PC866(Cyrillic#2), PC852(Latin2), PC858, IranⅡ, Latvian, Arabic, PT151(1251)
 Auto cutter  Full/Partial(optional)
 NV FLASH  256k bytes
 Input buffer  64K Bytes
 Power supply  DC 24V-2.5A
 Cash drawer control  DC 24V-1A
 Reliability  Printing head life: 100km Auto cutter life: 1 million cuts
 Working environment  Temperature (0~45 Degree C), humidity (10~80%)
 Storage environment  Temperature (-10~60 Degree C), humidity (10~90%)
 Drivers  Win 9X/Win 2000/Win XP/Win 7/Win 8/Win 8.1/Linux



 Command





 Compatible with ESC/POS


 Gross weight  1.16kg
 Dimension  184x144x136.8mm(L x W x H)






Product Accessories



Package includes:

80mm mini receipt printer x 1

USB data cable x 1

Poiwer cabke x 1

Power adapter x 1

Paper roll x 1

User manual x 1

ESC Windows Pos System Kitchen Thermal Label Printer









Application



Shopping malls, restaurants, stores, warehousing, taxation, banking, medical, postal

ESC Windows Pos System Kitchen Thermal Label Printer



FAQ



  • How to connect the 80MM printer with your software?
  • 1. Please install the printer first in your windows PC.
  • 2. Set the printer from your software "Printer Settings".
  • 3. If you don't know where to add printer in your software, please ask software supplier.



  • How to add LOGO on receipts?
  • 1. Connect the printer with windows PC via USB cable.
  • 2. Install printer driver on PC.
  • 3. Run "Setting Tool" in "Printer Driver".
  • 4. Enter "Advanced" setting, add "NV LOGO" and "Save".
  • 5. Restart the printer, you can print LOGO on every receipt then.
